15kg Light Rail Railway Steel Rail
Specification(KGS/M): 8Kg, 12Kg, 15Kg,18kg,22kg,24kg
Materials: Q235 55Q
Length:6,8,9,10m
Application: For mining/Engineering and so on
The list of China Coal Steel | ||||||
Name of Commodity | Specificaton | Materials (Steel Grade) | Standard of Products | Theory Weight (kgs/M) | Length of Dimension (M) | Packed In Bundle With Iron Wire (pcs/bundle) |
Light Rail | 4kgs/m | Q235 | Q/YYG001-2008 | 4kgs/m | 6,8,9,10 | 75 |
8kgs/m | Q235 | Q/YYG001-2008 | 8.42kgs/m | 55 | ||
12kgs/m | Q235 | GB11264-89 | 12.2kgs/m | 36 | ||
15kgs/m | Q235/55Q/50Q | GB11264-89 | 15.2kgs/m | 28 | ||
18kgs/m | Q235/55Q/50Q | YB222-63 | 18.06kgs/m | 21 | ||
22kgs/m | Q235/55Q/50Q | GB11264-89 | 22.3kgs/m | 21 | ||
24kgs/m | Q235/55Q/50Q | Q/YYG001-2008 | 24.46kgs/m | 21 | ||
30kgs/m | Q235/55Q/50Q | GB11264-89 | 30.1kgs/m | 15 | ||
